The long awaited and highly anticipated SIG:X Three Channel Tube Amplifier from VHT Amplification will begin arriving in stores in February. Described as “The best sounding (and feeling) amp I played at NAMM” by Matt Blackett of Guitar Player Magazine, the all new SIG:X (as in Your Signature Here), represents a new generation of VHT amplifiers.

Overview

Feature packed, yet simple and intuitive to operate, the SIG:X produces an astonishing array of tones and textures never before attainable from any single amplifier. Incorporating proprietary VHT design technology, top notch components, precision engineered transformers and legendary VHT build quality, the SIG:X is absolutely without peer in the guitar amplifier industry.

Players reactions at its 2008 NAMM debut ranged from spontaneous giggling to slack-jawed amazement as they played and watched the SIG:X produce an incredible palette of clean sounds on all 3 channels, then gradually morph from bluesy grit to fat chunky rhythms sounds and finally into a fire-breathing gain machine – all on only one of its three channels, and using only a stock vintage style strat.

Dowmload the Manual (PDF)


View Front Panel


View Back Panel


View Foot Switch



 Features & Specifications
  • Three independent channels with separate tone controls.
  • Three-Position PRE EQ VOICING switch for each channel allowing custom tailored tone shaping.
  • Exclusive VHT GAIN I/GAIN II Voicing and Overdrive configuration with channel assignable, footswitchable or manual (front panel) gain boost.
  • MORE/LESS MODE (Gain Stacking) for each High-Gain channel to select 3 or 4 Tube Gain stages on selected channel (channel assignable as on CL/UL models).
  • POWER SHIFT feature, a single mini toggle switch on each channel enables channel assignable Tube/SS Rectifier and 100W/40W output power selection (operates like ENHANCE MODE on Fifty/CL/ST).
  • Patented DYNAMIC SENSING feature (introduced in the GP3 pre) tracks string attack/decay to optimize sustain and note detail.
  • Two dedicated sets of Depth and Presence controls, one set for the Clean channel and one set for the LEAD and RHYTHM channels. Each set of Depth and Presence controls are voiced for their specific channels.
  • Footswitchable True-Bypass, Series/Parallel Effects Loop with level controls. Suitable for using the loop as a volume boost.
  • Smart Foot-controller selects LEAD, RHYTHM, CLEAN, BOOST and EFFECTS. Recalls previously selected combination of channel and boost/loop. Footswitch Boost and Effects functions can then used for gain boost (BOOST) or volume boost (EFFECTS) or both. Very cool with the recall feature.
  • One 16 ohm output jack is provided for connection to a 16 ohm cabinet. Two additional parallel jacks with a two position 8/4 ohm selector switch are provided.
  • A fixed level line out jack is also provided for direct recording or slaving.
  • Specifications:
    Output power: 100 Watts RMS max. 40 Watts RMS, low power mode.
    Size: 29-1/4W X 9H X 10-1/2D
    Weight: 53 pounds
  • Tube compliment:
    1 X 12AX7 Tung Sol
    5 X 12AX7A - Shuguang
    2 X KT88 – Sovtek – Premium Matched
    1 X 5U4G – EH
